What are pedestals used for?

The construction of hard landscaping areas including concrete paving slabs, porcelain tiles, natural stone slabs and timber, composite and metal decking for terraces, balconies, flat roofs and podium decks.

What are the advantages of using pedestals?

Improved drainage, ease and speed of installation, protection of the surface beneath, future-proofing (can be lifted at any time for maintenance). Lengthen the life of timber joists as they are lifted out of standing water.

How many will I need?

This all depends on your tile size, as well as the area and heights you require. We will let you know the measurements we require to help us calculate the correct quantity and type of pedestals you need.

How are they installed?

They are placed on a flat, hard surface/membrane. No mechanical fixings are required.

What subsurface do the pedestals work on?

A structured surface e.g. concrete or rigid insulation. They are not suitable for placing directly onto non-compacted earth.

How long will they last?

The pedestals are made of virgin plastic and are warrantied for 15 years.

How do I maintain a level surface on a slope?

Our Balance self-levelling pedestals will help provide a level finish to your new deck or paving and can be used to counter slopes of up to 5 degrees. If using our heavy duty Megapads, slope correctors are available.

Do the pedestals need to be fastened to the deck?

No. This is a suspended system. The pedestals are loose-laid – the weight of the slabs or decking hold everything in place – meaning the membrane is not compromised.

Can I place my decking boards directly on top of the pedestals?

No. Decking boards should be fixed to a joist grid which in turn can rest on top of the pedestals.

What additional support systems can I use pedestals with?

Pedestals can clip into our integrated rail system, connecting to a 2m long aluminium rail to support tiles or decking.

What heights do they come in?

Our pedestals come in a huge range of fixed and adjustable heights ranging from 5mm to 1,020mm.

How much gap do I need to leave between my paving slabs?

As standard, our heads are fitted with 2mm spacing but we also have 4mm.

How much weight can these take?

Even our standard Universal and Balance ranges are designed to take up to 680kg. If you have a commercial job that includes large planters or heavy objects, our Megapad range takes up to 2 tonnes.

Can the pedestals break?

We have never had a pedestal fail that was correctly installed since we launched the range in the UK in 2003.

Pedestals

Wallbarn-Adjustable-22-30mm-Minipad-for-Paving-Slab — Wallbarn Adjustable 22-30mm Minipad for Paving Slab

Wallbarn-Adjustable-22-30mm-Minipad-for-Porcelain-Paving — Wallbarn Adjustable 22-30mm Minipad for Porcelain Paving

Wallbarn-Adjustable-Minipad-for-Decking-10-25mm — Wallbarn Adjustable Minipad for Decking 10-25mm

Wallbarn-Adjustable-Minipad-for-Decking-22-30mm — Wallbarn Adjustable Minipad for Decking 22-30mm

Wallbarn-Adjustable-Minipad-for-Decking-28-40mm — Wallbarn Adjustable Minipad for Decking 28-40mm

Wallbarn-Adjustable-MiniPad-for-paving-10-25mm — Wallbarn Adjustable MiniPad for paving 10-25mm

Wallbarn-Adjustable-MiniPad-for-paving-22-30mm — Wallbarn Adjustable MiniPad for paving 22-30mm

Wallbarn-Adjustable-MiniPad-for-paving-28-40mm — Wallbarn Adjustable MiniPad for paving 28-40mm

Wallbarn-Adjustable-Minipad-Pedestal-22-30mm-with-Porcelain-Tiles — Wallbarn Adjustable Minipad Pedestal 22-30mm with Porcelain Tiles

MiniPad

Key Advantages

Suitable for paving, decking and rail system with different headpieces
Weight tolerance of 683kg with break point of over 1 tonne.
Can be laid in temperatures from ‐40°C to + 75°C.
Made from high quality virgin polypropylene
Perfect to achieve low height thresholds for paving or decking.
Resistant to sudden temperature changes, resists acid, alkaline and salts.
Special handle grips allow installers to adjust the height whilst slab is in situ – saves constantly lifting the slab to change the height

MiniPad Pedestals range in height from 10mm to 40mm Click Here

Project Enquiry Gallery Specification

Have an ultra-low threshold? Try our Minipads range. Our time-saving alternative to fixed height pads and perfect for overlaying and retro-fitting. Available from 10mm to 40mm in just three products:

10-25mm
22-30mm
28-40mm

Product benefits:

Achieve precise, split-millimetre accuracy in the height of the pedestal to accommodate tiny changes in the level.
Designed for use when working with very tight spaces
Thread allows 5mm of change to the level
Further 5mm extension plate which is fitted to the bottom of the pedestal
5mm extension plate turns 10-15mm pedestal into a 15-20mm fully adjustable pedestal for use in tight spaces
Special handle grips allow installers to adjust the height whilst slab is in situ – saves constantly lifting the slab to change the height
